Maintenance and storage

a) Keep all nuts, bolts, and screws tight to be sure the machine is in safe

working condition.

b) Check the grass collector frequently for wear or deterioration.

c) Replace worn or damaged parts for safety.

d) On machines with multi blade, take care as rotating one blade can cause

other blades rotate.

e) Be careful during adjustment of the machine to prevent entrapment of the

fingers between moving blades and fixed parts of the machine.

f) Always allow the machine to cool down before storing.

g) When servicing the blades be aware that, even though the power source is

switched off, the blades can still be moved.

h) Use only genuine replacement parts and accessories.

Additional safety warnings

Electrical safety

DANGER! Cardiac arrest!

This product makes an electromagnetic field while it operates. This field

may under some conditions interfere with active or passive medical

implants. To decrease the risk of conditions that can possibly injure or

kill, we recommend persons with medical implants to speak with their

physician and the medical implant manufacturer before you operate the

product.

Before use, examine the cable for signs of damage or ageing. If the cable is

found to be defective, take the product to an authorised Service Centre and have

the cable replaced.

Do not use the product if the electric cables are damaged or worn.

Immediately disconnect from the mains if the cable is cut, or the insulation is

damaged. Do not touch the electric cable until the cable has been disconnected.

Do not repair a cut or damaged cable. Replace it with a new one.

The extension cable must be uncoiled. Coiled cables can overheat and reduce

the efficiency of your mower.

Keep the extension cable away from product, always work away from the power

point mowing up and down, never in circles.

Do not pull cable around sharp objects.

Always switch off at the mains before disconnecting any plug, cable connector

or extension cable.

Stop the motor, disconnect the mains and examine the cable for damage or

ageing before you wind the cable for storage. Do not repair a damaged cable,

replace it with a new one. Use only genuine replacement cable.

Always wind the cable carefully, avoid kinking.

Do not carry the product by the cable.

Do not pull on the cable to disconnect any of the plugs.

Use only on AC mains supply voltage shown on the product rating label.

Our products are double insulated to EN60335. Do not connect an earth to

any part of the product.

Check the working area for hidden cables.

Do not use for pond care or close to water.

Personal safety

DANGER! Risk of suffocation!

Small parts can be easily swallowed. There is also a risk that the poly-

bagcan suffocate toddlers. Keep toddlers away when you assemble the

product.

Let the hover mower to cool down for at least 30 minutes before storage or

maintenance.

If blockage of cutting element stop product and check.

Do not tilt the machine into the direction of the user.

Do not move backwards.

Stay alert during operation.

Do not use in explosive atmosphere.

Do not operate the product when you are tired, ill or under the influence of

alcohol, drugs or medicine or when you are exhausted.

Do not overload the mower.

Use gloves, wear slip resistant shoes and wear eye protection.

Do not use under wet conditions.

Do not use on wet grass.

Do not disassemble the product further than the delivery status.

Only start the mower with an upright standing handle.

Do not use the start levers alternately.

Use the handles carefully.

Safety Cut-Out

The motor is protected by a Safety Cut-Out which is activated when the blade

becomes jammed or if the motor is overloaded. When this occurs, stop and dis-

connect the product from the mains. The Safety Cut-Out will only reset when you

release the start / stop lever. Clear any obstruction and wait for a few minutes for

the Safety Cut-Out to reset before you continue to use the product.

2. ASSEMBLY

DANGER! Risk of injury!

Cut injury when the product starts accidentally.

v Wait for the blade to stop, disconnect the product from the

mains and use gloves before you assemble the product.

To assemble the lower handle [ Fig. A1 ]:

1. Place the end of the lower handle

1

into the slots on the deck

2

.

2. Secure the lower handles

1

to the deck

2

by firmly pushing fixing

pin

3

through the holes in the deck

2

and handle

1

.

3. Repeat on the other side.

NOTE: Should a problem occur when securing the handle to the deck

with the fixing pin, carefully lever fixing pin out of location and repeat

steps 1 to 3 above.

To assemble the upper handle [ Fig. A2 / A3 ]:

1. Make sure that the upper handle

4

is located correctly with the safety

lock-off button

5

on the switchbox facing upwards.

2. Make sure that the upper handle

4

and the lower handle

1

are aligned

correctly.

3. Insert the nut into the handle knob

6

(if necessary).

4. Fit the bolts

8

, the washers

7

and the handle knobs

6

onto the

handles

1

/

4

in the correct positions.

5. Attach the cable

9

to the handles

1

/

4

with the clips

0

provided.

Make sure that the cable

9

is not trapped between the upper

handle

4

and lower handle

1

.

3. OPERATION

DANGER! Risk of injury!

Cut injury when the product starts accidentally.

v Wait for the blade to stop, disconnect the product from

the mains and use gloves before you adjust or transport

the product.

To connect the mower [ Fig. O1 / O2 ]:

DANGER! Electric shock!

To avoid damage to the extension cable

q

, the extension

cable

q

must be inserted into the cable lock

-

.

v Before you operate insert the extension cable

q

into the cable

lock

-

.

1. Connect the female extension cable

q

connector to the back of the

switchbox

w

.

2. Form a loop in the extension cable

q

, insert the loop into the cable

lock

-

slot in the switchbox

w

and pull tight.

3. Connect the extension cable

q

into a 230 V mains socket.

To adjust the cutting height [ Fig. O3 / O4 / O5 ]:

CAUTION! Do not use more than 3 cutting height

spacers

e

. The cutting height spacers

e

must only be fitted

between the blade

r

and the fan

t

. Do not fit the cutting height

spacers

e

between the blade

r

and the blade bolt

z

.

1. To remove the blade bolt

z

, hold the fan

t

firmly and loosen the blade

bolt

z

with the spanner

u

provided.

2. Remove the blade bolt

z

, the blade

r

, the cutting height spacers

e

and the fan

t

.

3. Inspect for damage and clean as necessary.

4. Put the fan

t

on the product.

Make sure that the fan

t

is fully in place and the hole of the fan is inline

up with the threaded hole.

5. Put the cutting height spacers

e

onto the fan

t

.

Higher Cut – less cutting height spacers

Lower Cut – more cutting height spacers

Make sure that the pegs have located into the holes.

6. Put the blade

r

on by aligning the D-shaped holes onto the cutting

height spacers

e

.

Make sure that the pegs have located into the holes on the blade.

EN

5
