15
BDSE 12 T ST BDSE 14 T ST B 14 T SB2E 12 T ST
............12 mm ....................12 mm .............12 mm .............. 12 mm
............26 mm ....................28 mm .............28 mm .............. 26 mm
...............- ............................ - ..................... - mm .............. 13 mm
..............8 mm ......................8 mm ...............8 mm ................ 8 mm
.......0-360 min
-1
............. 0-400 min
-1
...... 0-400 min
-1
........ 0-360 min
-1
.....0-1000 min
-1
............0-1100 min
-1
.....0-1100 min
-1
...... 0-1000 min
-1
............ 11 Nm .....................13 Nm ..............13 Nm ............... 11 Nm
............25 Nm .....................28 Nm ..............28 Nm ............... 25 Nm
.....22 / 10 Nm ..............38 / 16 Nm .......38 / 16 Nm .......... 19 / 9 Nm
.........880 / 350 .............1050 / 420 ...... 1050 / 420 ...........880 / 350
............. 300 ....................... 360 ..................360 .................... 300
............. 320 ....................... 385 ..................385 .................... 320
............. 420 ....................... 500 ..................500 .................... 420
............12 V .....................14,4 V ..............14,4 V .................. 12 V
......1,5-13 mm ............. 1,5-13 mm ...... 1,0-10 mm ........1,5-13 mm
...........1,8 kg .....................2,4 kg ..............2,4 kg ............... 2,0 kg
.........< 70 dB (A) .............< 70 dB (A) ..... < 70 dB (A) .......... 87 dB (A)
................ .............................. ....................... .................... 98 dB (A)
..........< 2,5 m/s
2
..................< 2,5 m/s
2
...........< 2,5 m/s
2
.................11 m/s
2
ENGLISH
TECHNICAL DATA
Drilling capacity in steel ..................................................................
Drilling capacity in wood .................................................................
Drilling capacity in brick and tile .....................................................
Wood screws (without pre-drilling) .................................................
No-load speed, 1st gear .................................................................
No-load speed, 2nd gear ................................................................
Torque *1
Soft wood max. ............................................................................
Steel plate max. ...........................................................................
Static jamming moment, 1st gear/2nd gear .................................
Screwing capacity with one fully charged battery (1.4 Ah) : *2
M6x10 / M10x20 Steel plate .......................................................
5x40 Soft wood ...........................................................................
Drilling capacity with one fully charged battery (2,4 Ah):
ø 3 mm Steel plate 1,6 mm .........................................................
ø 6 mm Soft wood 20 mm ...........................................................
Battery voltage ...............................................................................
Drill opening range .........................................................................
Weight with battery .........................................................................
Typical A-weighted sound levels:
Sound pressure level (K = 3 dB(A)) ..............................................
Sound power level (K = 3 dB(A)) ..................................................
The noise level when working can exceed 85 dB (A).
Wear ear protectors!
Typical weighted acceleration in the hand-arm area ......................
Measured values determined according to EN 60 745.
SAFETY INSTRUCTIONS
Please pay attention to the safety instructions in the attached
leaflet!
Always wear goggles when using the machine. It is
recommended to wear gloves, sturdy non slipping shoes and
apron.
Sawdust and splinters must not be removed while the machine is
running.
When working in walls ceiling, or floor, take care to avoid electric
cables and gas or waterpipes.
Dust that arises when working on material containing asbestos
or stonework containing crystalline silicic acid is harmful to the
health. Please follow accident prevention regulations.
Remove the battery pack before starting any work on the
machine.
Do not dispose of used battery packs in the household refuse or
by burning them. AEG Distributors offer to retrieve old batteries
to protect our environment.
Do not store the battery pack together with metal objects (short
circuit risk).
Use only System 3000 chargers for charging System 3000
battery packs. Do not use battery packs from other systems.
No metal parts must be allowed to enter the battery section of
the charger (short circuit risk).
Never break open battery packs and chargers and store only in
dry rooms. Keep dry at all times.
Battery acid may leak from damaged batteries under extreme
load or extreme temperatures. In case of contact with battery
acid wash it off immediately with soap and water. In case of eye
contact rinse thoroughly for at least 10 minutes and immediately
seek medical attention.
SPECIFIED CONDITIONS OF USE
BDSE 12 T Super Torque, BDSE 14 T Super Torque: The battery
drill/screwdriver is designed for drilling and screwdriving for
independent use away from mains supply.
SB2E 12 T Super Torque: The electronic battery percussion drill/
screwdriver is designed for drilling, percussion drilling, as well as
screwdriving for independent use away from mains supply.
Do not use this product in any other way as stated for normal
use.
EC-DECLARATION OF CONFORMITY
We declare under our sole responsibility that this product is in
conformity with the following standards or standardized
documents. EN 60745, EN 55014-1, EN 55014-2, in accordance
with the regulations 98/37/EEC, 89/336/EEC
Volker Siegle
Manager Product Development
BATTERIES
New battery packs reach full loading capacity after 4 - 5
chargings and dischargings. Battery packs which have not been
used for some time should be recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance
of the battery pack. Avoid extended exposure to heat or sunshine
(risk of overheating).
The contacts of chargers and battery packs must be kept clean.
MAINTENANCE
Use only AEG accessories and spare parts. Should components
need to be replaced which have not been described, please
contact one of our AEG service agents (see our list of guarantee/
service addresses).
If needed, an exploded view of the tool can be ordered. Please
state the Article No. as well as the machine type printed on the
label and order the drawing at your local service agents or
directly at: AEG Elektrowerkzeuge, Max-Eyth-Straße 10,
D-71364 Winnenden, Germany.
SYMBOLS
Accessory - Not included in standard
equipment, available as an accessory.
Remove the battery pack before starting any
work on the machine.
*1 Measured according to AEG norm N 877318
*2 The values stated are reference values. Actual values might differ, depending on the material and quality of the screws.
