Ferm 35
AVAILABLE SPARE PARTS FOR FZT-250
EXPLODED VIEW 1
REF.NR. DESCRIPTION FERM NR.
1/2/3 SAWBLADE COVER COMPLETE 407460
13-18 ANGLE GAUGE COMPLETE 407461
19/20 TABLE INSERT 407462
22-35 SAWGUIDE COMPLETE 407463
45 GEAR SHAFT 407464
46 KEY 407465
47 GEAR 407466
54 ROTOR 407467
56 STATOR 407468
59/60/61 CARBON BRUSH + HOLDER 407469
81 HEX. NUT M16 x 1.5 407472
82 OUTSIDE FLANGE 407470
83 HARD METAL SAW BLADE 250 x 30 x16, T36 327252
83 HARD METAL SAW BLADE 250 x 30 x 16, T30 310360
84 INSIDE FLANGE 407471
103 CRANK 407473
111 MAGNETIC SWITCH 407474
115/116 FIXED BRACKET + RING 407475
Product: Ferm saw-bench
Type FZT-250, Art. nr. 420085
Ferm, Genemuiden, the Netherlands
Sound pressure level (L
pa
) 85 dB(A)
Acoustic capacity level (L
wa
) 99 dB(A)
Measurements of bench 685 x 430 mm
Suction mouth Ø 30 (22) mm
SERIAL NUMBER
The serial number on the machine is composed as fol-
lows:
Serial nr.
READ THESE INSTRUCTIONS FOR USE
PROPERLY BEFORE YOU USE THE SAW-
BENCH!
1. SPECIAL SAFETY
INSTRUCTIONS
1. When using the saw blades with hard metal teeth
(widia) it is advisable to use blades with a negative
or slightly positive cutting angle. Do not use any
saw blades with deeply cut teeth. They can grip the
protective cap.
2. Attention: First carefully assemble all the parts be-
fore starting work. Follow the procedure as indica-
ted.
3. If you are not familiar with using such a machine,
you would be better to be informed first by a pro-
fessional, an instructor or by a technician.
4. Always clamp or press the workpiece firmly
against the saw guide, before you carry out the
process. The use of all possible clamping set-ups is
preferable to using your hands.
5. Important: If you are holding the workpiece by
hand for the process to be carried out, keep a mini-
mum distance of 100 mm from the saw blade.
6. Always press the workpiece against the bench.
7. Keep the saw blade sharp and check regularly
whether it rotates freely without abnormal vibra-
tions. Replace the saw blade if necessary.
8. Allow the machine to rotate freely until it reaches
the maximum number of revolutions, before you
start the process.
9. Maintain the air inlets at the back and the bottom of
the bench saw machine and electric engine for a
longer machine life. Dust piles must be removed.
10. Always lock the different degree set-ups before
you start processing.
11. Only buy suitable saw blades with a number of re-
volutions of at least 6000 revolutions per minute.
12. Only use the correct saw blade. Too small or too
big saw blades are extremely dangerous.
13. Regularly inspect the saw blade for any faults. Re-
place the saw blade if necessary.
14. Grease the new saw blade and clean the flanges be-
fore you assemble the new blade. Then assemble
the blade in the correct direction and pull the flan-
ges firmly using the central bolt (left thread!)
15. Only use original flanges. All other types are not
suitable.
16. Never work without the protective cap of the saw
blade.
17. The moving part of the protective cap must also re-
main assembled.
18. Never grease the saw blade while it is rotating.
19. Always keep your hands removed from the track
of the saw blades.
20. Never pick up the workpiece by grasping with your
hands along or behind the saw blade.
21. Ensure that the workpiece never touches the saw
blade, before the machine has been switched on.
22. Never process metal or stone sorts with this ma-
chine.
23. Use support aids in order to support long work-
pieces.
24. Never use the machine in a dangerous environ-
ment, where inflammable gases or fluids are pre-
sent.
25. Never leave the machine unattended without first
disconnecting it from the mains voltage.
26. If you hear abnormal noises, try to trace them or
take the machine to a recognized fitter, or repair
company.
27. If a part is broken or damaged, replace it or repair it
immediately.
28. Never stand in the track of the saw blade but stand
to the left or the right of the saw bench.
29. Your hands must likewise be placed next to the
track of the saw blade.
30. Never use a wooden pole instead of your hands to
push the wood through the saw.
31. Always place the wood at the front of the saw ben-
ch and then push it further back.
ORDER NUMBER / CONSTRUCTION YEAR
GB
English
2 Ferm
VOLT WATT RPM mm mm mm kg
230V~50Hz 1.5 kW 4500 55 80 Ø 254 x 1,6 x 16 22
40 Teeth
45°
MM
1'
90°
MM
kg.
IP
20
