Bruksanvisning Asaklitt 34-8544 Skritteller

Bruksanvisning

GREAT BRITAIN

For consumer contact, please visit www.clasohlson.co.uk and click on customer service.

ENGLISH

SET

MODE

UP/CLR

DOWN

PEDOMETER

STOP/TIME

PM

3730

12:38

45

S1

S2

S3

S4

Ver. 201106

Step Counter

Art.no. 34-8544

Please read the entire instruction manual before using the product

and save it for future reference. We reserve the right for any errors

in text or images and any necessary changes made to technical

data. If you have any questions regarding technical problems

please contact Customer Services.

Buttons and functions

Operation

• To reset the step counter press and hold [ UP/CLR ].

Distance meter + stop watch (DIST/STW)

1. Push [ MODE ] to use the distance meter and stopwatch.

The distance will be displayed on the top row while

the stopwatch will be displayed on the bottom row.

2. Push [ SET ] in order to start and stop the stopwatch.

3. Press [ UP/CLR ] to reset.

Calorie counter + ODO setting (KCAL/ODO)

1. Push [ MODE ] twice to use the calorie counter.

2. The number of burned calories is shown on the top row

while the total distance is shown on the bottom row.

3. The total distance can only be reset by changing or

removing the batteries.

Setting the calories + daily calorie settings

(SETCAL/DAYCAL)

1. Push [ MODE ] three times to use the calorie counter and

daily calorie settings.

2. The target goal for burned calories will be displayed on

the top row while the actual number of calories burned

will be shown on the bottom row.

3. A gauge is shown on the top part of the display which

represents what percent of the target value has been

reached.

4. Both the daily calories and gauge are automatically reset

every day.

5. Press [ SET ] to set the target value. The first value on

the left will begin flashing. Use [ UP/CLR ] and [ DOWN ] to

select and [ SET ] to continue on to the next value.

Push [ SET ] to confirm.

6. Remember that only calories burned can be reset and

not step counting.

Wearing the step counter

• Attach the step counter to a belt or to other type of

clothing at waist height on either side of your body.

For the step counter to function correctly it is important

that it is attached in a horizontal position.

S1 – [ MODE ]

S2 – [ SET ]

S3 – [ DOWN ]

S4 – [ UP/CLR ]

Preparations

Setting the time and personal data

1. Press [ SET ] until ”12hr” begins flashing on the display.

2. Press [ UP/CLR ] or [ DOWN ] to switch between a 12/24

clock setting. AM/PM will not be displayed when

selecting the 24-hour clock setting. Press [ SET ] to

confirm to continue setting the hours.

3. Use [ UP/CLR ] and [ DOWN ] to set the hours. Keep the

button depressed for quicker response. Confirm with [ SET ].

4. Use [ UP/CLR ] and [ DOWN ] to set the minutes. Keep the

button depressed for quicker response. Confirm with [ SET ].

5. Setting personal data: Use [ UP/CLR ] and [ DOWN ] to set

your step length and weight. Push [ SET ] to confirm.

Using the assault alarm

Activation: Pull out the alarm pin from the back of

the step counter to activate the assault alarm.

Deactivation: Replace the alarm pin to turn off the alarm.

Changing the batteries

1. Press down on the belt clip so that you can gain access

to the battery cover. Loosen the safety screw on

the battery cover and remove it.

2. Lift out the batteries with the help of a fine screwdriver

and replace them with new ones. Be careful to insert

the batteries with the polarities facing the correct

direction according to the figure.

Disposal

Follow local ordinances when disposing of this product.

If you are unsure of how to dispose of this product,

please contact your municipality.

Specifications

Battery, step counter 1 x SR54/CR1130 (included)

Battery, assault alarm 2x CR2016 (included)

Step counter Up to 99 999 steps

Calorie counter Up to 9999.9 kcal

Distance Up to 9999.9 km/miles
